ELEVATE 606 – Commercial Frontglaze Frames 152 x 50mm

HOME > PRODUCTS COMMERCIAL WINDOWS & DOORS

Series 606 FrontGLAZE™ is designed to complement Series 406 FrontGLAZE™, Series 702 and 704 SlideMASTER™ sliding doors.

  • High water resistance can be achieved, the design has been successfully tested at 600Pa water resistance.
  • Variety of transom and mullion alternatives.
  • Industry standard glazing pocket as per Series 406 FrontGLAZE™ and Series 400 CentreGLAZE™, incorporates a truly captive glazing wedge.
  • Two mullion designs allow frames to be constructed with snap together mullion and expansion mullion with central weather leg for improved waterproofing.
  • Two midrail sizes (50mm and 125mm).
  • Large variety of glazing and beading options.
  • Built-in drip groove on transoms to encourage water to leave framing face.
  • Sills and transoms are splayed at 25º to reduce the chance of dust and pollution build-up.
  • Doors can be fitted with matching 25º splayed horizontal beads.
  • Will accept awning/casement sash inlays.

General

Maximum Panel Height* Various
Maximum Panel Width* Various
Maximum Glass Thickness ≤ 10.38mm
SHGC Range 0.33 – 0.74
Uw Range 4.5 – 6.4
