ELEVATE 406 – Commercial Frontglaze Frames 102 x 50mm


Series 406 FrontGLAZE™ framing is designed to complement other AWS framing and doors.

  • High water resistance can be achieved successfully tested at 600Pa water resistance.
  • Large variety of transom and mullion alternatives, Series 406 will also accept many of the Series 400 CentreGLAZE™ frame accessories including doors, sub-frames and thresholds.
  • Industry standard glazing pocket with true captive glazing wedge.
  • Three mullion designs allow frames to be constructed with snap together mullion and expansion mullion with central weather leg for improved waterproofing.
  • Two midrail sizes (50mm and 125mm).
  • Large variety of glazing and beading options.
  • Built-in drip groove on transoms to encourage water to leave framing face.
  • Sills and transoms are splayed at 25º to reduce the chance of dust and pollution build-up.


Maximum Panel Height* Various
Maximum Panel Width* Various
Maximum Glass Thickness ≤ 10.38mm
SHGC Range 0.25 – 0.74
Uw Range 4.5 – 6.1
