VANTAGE 506 – Residential Sliding Windows


Calling all West Australians! This stunning aluminium sliding window from the Vantage® Residential Series is designed specifically with you in mind.

An excellent choice, practical and non-projecting. Single or double opening panels can be specified, along with double glazing where improved thermal or acoustic performance is required.

  • 72mm frame.
  • Wide sash wheels so your windows always run smoothly.
  • The option of high-performance sills if your home is exposed to harsh elements.
  • Flyscreens that tuck neatly into the head and sill – no more ugly rivets.
  • Built-in sill drainage for reduced condensation.


Maximum Panel Height* 1500mm
Maximum Panel Width* 1050mm
Maximum Glass Thickness ≤ 6.76mm
SHGC Range 0.3 – 0.73
Uw Range 3.2 – 6.4
